A collection of demonstration scenarios is provided to showcase the capabilities of the PVA ISP on NVIDIA Jetson platforms. Each scenario is designed to be reproducible using readily available hardware while illustrating common image processing challenges in embedded vision applications.
Demo Hardware Platform
All demonstrations use the following hardware configuration.
| Component | Description |
|---|---|
| Processing Platform | NVIDIA Jetson AGX Orin |
| Camera Sensor | Sony IMX274 |
| Camera Interface | MIPI CSI-2 |
| ISP | RidgeRun PVA ISP |
| Output Format | NV12 |
Additional mounting accessories may be used depending on the demonstration scenario.
Figure 1. Reference hardware setup used for PVA ISP demonstrations.
Indoor Security Camera
This demonstration simulates a security camera monitoring an indoor residential environment.
 | lleon: The contents seem too synthetic (AI). Some graphs regarding the pipeline and previews of the expected results are more appealing. (please remove this box when addressed) |
Objective
Demonstrate image processing under controlled indoor lighting conditions.
Camera Placement
The IMX274 camera is mounted on a tripod inside a meeting room or office area.
Suggested locations:
- Conference room
- Open workspace
- Office entrance
The camera should observe:
- People walking
- Doors opening and closing
- Desks and furniture
- Static and moving objects
ISP Algorithms Demonstrated
- Black Level Correction
- Auto White Balance
- Demosaicing
- Gamma Tone Mapping
Expected Results
- Improved color consistency
- Stable image brightness
- Enhanced visibility of indoor details
Figure 2. Indoor security camera demonstration setup.
Outdoor Security Camera
This demonstration simulates a surveillance camera monitoring the exterior of a building.
Objective
Demonstrate ISP behavior under challenging outdoor lighting conditions.
Camera Placement
The IMX274 camera is mounted on a tripod near the exterior of the Plaza Magnolia office.
Suggested targets:
- Parking lot entrance
- Sidewalk traffic
- Building entrances
- Moving vehicles
The scene should contain:
- Direct sunlight
- Shadows
- Reflections
- Pedestrians
ISP Algorithms Demonstrated
- Auto White Balance
- Global Tone Mapping
- Gamma Tone Mapping
Expected Results
- Improved shadow detail
- Better color balance
- Improved visibility under varying illumination
Figure 3. Outdoor security camera demonstration setup.
Traffic Monitoring Camera
This demonstration simulates a traffic monitoring system.
Objective
Demonstrate image preprocessing for vehicle detection and traffic analytics.
Camera Placement
The camera is mounted on a tripod facing a nearby roadway around Plaza Magnolia.
Suggested targets:
- Vehicles
- Motorcycles
- Pedestrians
- Traffic signals
The camera should remain fixed during capture.
ISP Algorithms Demonstrated
- Demosaicing
- Global Tone Mapping
- NV12 Conversion
Expected Results
- Enhanced vehicle visibility
- Consistent image quality
- Improved downstream AI performance
Figure 4. Traffic monitoring demonstration setup.
In-Vehicle Camera
This demonstration simulates an automotive forward-facing camera.
Objective
Demonstrate image processing for automotive perception workloads.
Camera Mounting
The IMX274 camera is mounted inside a vehicle using:
- Windshield suction mount
- Small tripod attached to the dashboard
- Custom camera holder
The camera should face forward through the windshield.
Capture Route
Suggested route:
- Plaza Magnolia parking area
- Local streets
- Commercial areas
- Residential roads
The captured scene should include:
- Buildings
- Vehicles
- Pedestrians
- Traffic signs
- Variable lighting conditions
ISP Algorithms Demonstrated
- Auto White Balance
- Demosaicing
- Global Tone Mapping
Expected Results
- Improved visibility of road features
- Stable image quality during motion
- Enhanced detail in high-contrast scenes
Figure 5. In-vehicle camera demonstration setup.
